CM2 HexaMesh Iso

current version: 5.5.2 (February 2025)

Solid Hexahedral Mesh Generator (isotropic)

CM2 HexaMesh Iso is a Delaunay isotropic hex-dominant mesh generator for your FEA (Finite Element Analysis) applications.

CM2 HexaMesh Iso offers unique features among the very few available hex mesh generators today:

  • CM2 HexaMesh Iso is a true Delaunay hex-dominant mesh generator respecting user-defined constraints: outer and inner boundary faces, specific embedded faces, edges and nodes, local mesh sizes (isotropic), maximum size gradations and background mesh.
  • CM2 HexaMesh Iso accepts all-quad, hybrid (quad-dominant) or all-triangle boundary meshes (extern or embedded).
  • CM2 HexaMesh Iso generates a high ratio of hexahedrons (bricks) and wedges. Some pyramids and tetrahedrons are also usually required.
  • High-order elements, for instance quadratic 10-node tetrahedrons, 14-node pyramids, 18-node prisms and 26/27-node hexahedrons (bricks), can be generated with the help of CM2 MeshTools SDK Core functions (provided free of charge with all licenses).
  • Like the other mesh generators of the CM2 MeshTools SDK, CM2 HexaMesh Iso is written in modern C++.
    A COM interface is also available for others Windows .Net languages (managed C++, C#, Visual Basic…)

Examples

Technical
Specifications

  • Solid mesh generator
  • Isotropic
  • Hybrid Advancing-front & Delaunay
  • 4‑node quads and 3‑node triangles (outer/embedded), 2‑node edges (embedded), inner nodes (embedded)
  • 8‑node hexahedrons, 6‑node prisms, 5‑node pentahedrons, 4‑node tetrahedrons
  • yes
  • ≥ 2 000 elements / s.

*Speed tests done on Win10 x64 Pro, Intel® Xeon E3 v2 1370 @3.5 GHz (turbo boost disabled), 8 threads.

Strong Foundations

CM2 HexaMesh Iso is written in streamlined standard C++ with a clear API.

Pre-compiled dynamic libraries and source code are available for Microsoft Windows, Linux and Apple macOS.
Visit the CM2 MeshTools SDK page to learn about all the provided builds.

Easy Integration with C++ on Microsoft Windows, Linux and Apple macOS

A COM interface is also available making CM2 HexaMesh Iso callable from other languages such as Visual Basic, C#, F# and Delphi.

Microsoft .NET, Visual Studio, C-Sharp, F-Sharp and Delphi also available
