CM2 SurfMesh T3

current version: 5.4.1 (March 2024)

Surface Triangle Mesh Generator for CAD Models

CM2 SurfMesh T3 is a surface triangle mesh generator based on CM2 TriaMesh Aniso and OpenCascade (OCCT).

Main features:

  • Target mesh size, maximal chordal error, maximal size gradation.
  • CM2 SurfMesh T3 can automatically repair topological errors of the CAD model (it can merge close vertices and close curves).
  • Meshes on the 3D surfaces can be isotropic (equilateral triangles as good as possible) or anisotropic to reduce the number of elements keeping the same chordal error (stretched triangles on fillets for instance).
  • CM2 SurfMesh T3 can generate 6-node triangles with mid-nodes projected onto the exact CAD surfaces (curved triangles) or not (plane triangles).
  • CM2 SurfMesh T3 can read STEP, IGES and B-Rep files or mesh directly any OCCT TopoDS_Shape object.

Technical
Specifications

  • Surface mesh generator
  • Isotropic or anisotropic
  • Hybrid Advancing-front & Delaunay
  • CAD models (B-Rep, IGES or STEP) or TopoDS_Shape OCCT objects
  • 3-node or 6-node triangles (3D)
  • yes
  • ≥ 9 000 elements / s.

*Speed tests done on Win10 x64 Pro, Intel® Xeon E3 v2 1370 @3.5 GHz (turbo boost disabled), 8 threads.

Strong Foundations

CM2 SurfMesh T3 is written in streamlined standard C++ with a clear API.

Pre-compiled dynamic libraries and source code are available for Microsoft Windows, Linux and Apple macOS.
Visit the CM2 MeshTools SDK page to learn about all available builds.

Easy Integration with C++ on Microsoft Windows, Linux and Apple macOS
